ORIGINAL PAPER
Improving the stiffness of the corner connections in wooden door frames
More details
Hide details
1
-, PORTA KMI Poland, Poland
2
Faculty of Forestry and Wood Technology, Poznan University of Life Sciences, Poland
3
Faculty of Wood Sciences and Technology, Technical University in Zvolen, Slovak Republic
4
-, Łukasiewicz Research Network - Poznań Institute of Technology, Poland
5
-, General Engineering Solutions, Poland
Submission date: 2025-02-13
Final revision date: 2025-04-09
Acceptance date: 2025-04-22
Online publication date: 2025-07-11
Corresponding author
Marta Pędzik
-, Łukasiewicz Research Network - Poznań Institute of Technology, 6 Ewarysta Estkowskiego St., 61-755, Poznań, Poland
KEYWORDS
TOPICS
ABSTRACT
The research aimed to determine the strength and stiffness of corner joints in interior door frames, depending on their construction and the modifications made to the design of the door frame joints. Initially, two models were compared: model 1, with two connectors using a clamping screw at an angle of 45°, and model 0, with a single connector using a cam joint at an angle of 90°. In all tests, model 1 exhibited significantly better mechanical properties. To improve the performance of model 0, three alternative construction models (A, B, and C) were proposed by changing the position of the door frame mounting holes. In the compression test, model A showed an increased bending moment compared to model 0, while models B and C showed no such improvement. In the tension test, the bending moment values remained at a similar level across all construction variants, including model 0. In terms of bending moment, the best result in compression was achieved by model A (48.26 Nm), and in tension by model B (48.72 Nm). The highest stiffness was demonstrated by model 1 (up to 42.38 kNm/rad), while among the alternative models, model C showed the best result in tension (33.98 kNm/rad). Due to the favourable increase in bending moment under compression in model A and the insignificant changes under tension across all variants, model A is considered the optimal solution. To enhance the strength of the door frame, offset holes can be applied as proposed in this model.
REFERENCES (19)
1.
Altun, S., B.E., K., 2010. Effect of adhesive type on the bending moment capacity of miter frame corner joints. Bioresources 5, 1473–1483.
2.
Branowski, B., Starczewski, K., Zabłocki, M., Sydor, M., 2020. Design issues of innovative furniture fasteners for wood-based boards. Bioresources 15, 8472–8495.
https://doi.org/10.15376/biore....
3.
Demirel, S., Sen Er, R., 2022. Evaluation and comparison of control and heat treated L-shape furniture joints produced from Scotch pine and ash wood under static bending and cyclic fatigue bending loadings. Maderas. Ciencia y tecnología 24.
https://doi.org/10.4067/S0718-....
4.
Demirel, S., Zhang, J., Wang, Y., 2024. Bending fatigue performance of L-shaped stapled one-side two-gusset-plate upholstered furniture joints in oriented strandboard. European Journal of Wood and Wood Products 82, 493–502.
https://doi.org/10.1007/s00107....
5.
Hu, W.-G., Luo, M., Hao, M., Tang, B., Wan, C., 2023. Study on the Effects of Selected Factors on the Diagonal Tensile Strength of Oblique Corner Furniture Joints Constructed by Wood Dowel. Forests 14, 1149.
https://doi.org/10.3390/f14061....
6.
Jensen, J.L., Sasaki, T., Koizumi, A., 2002. Plywood frame corner joints with glued-in hardwood dowels. Journal of Wood Science 48, 289–294.
https://doi.org/10.1007/BF0083....
7.
Johanides, M., Kubíncová, L., Mikolášek, D., Lokaj, A., Sucharda, O., Mynarčík, P., 2020. Analysis of Rotational Stiffness of the Timber Frame Connection. Sustainability 13, 156.
https://doi.org/10.3390/su1301....
8.
Karaman, A., Y.M.N., 2021. Effects of Wood Species of The Dowels and Fiber Woven Fabric Types on Bending Moment Resistance of L-Shaped Joints. Wood Industry and Engineering 3, 12–22.
9.
Kasal, A., Smardzewski, J., Kuşkun, T., Güray, E., 2023. Analyses of L-Type Corner Joints Connected with Auxetic Dowels for Case Furniture. Materials 16, 4547.
https://doi.org/10.3390/ma1613....
10.
Krzyżaniak, Ł., Kuşkun, T., Kasal, A., Smardzewski, J., 2021. Analysis of the Internal Mounting Forces and Strength of Newly Designed Fastener to Joints Wood and Wood-Based Panels. Materials 14, 7119.
https://doi.org/10.3390/ma1423....
11.
Kwidziński, Z., Drewczyński, M., Gołąbek, T., Myszka, R., Wilczyński, A., Gębczyk, K., Filipczuk, P., Prałat, B., Rogoziński, T., 2023. The efficiency of the formatting and milling module of the technological line for door frames production. Annals of WULS, Forestry and Wood Technology 121, 72–78.
https://doi.org/10.5604/01.300....
12.
Lao, W.-L., Ma, L.-P., Wang, C., Liu, C.-W., Li, Y., 2023. Environmental impacts evaluation and promotion measures of wood-based composite doors. Journal of Building Engineering 108164.
https://doi.org/10.1016/j.jobe....
13.
OB-RPPD, 2023. Biuletyn informacyjny Ośrodka Badawczo-Rozwojowego Przemysłu Płyt Drewnopochodnych w Czarnej Wodzie 1–2, 5–116.
14.
Pędzik, M., Bednarz, J., Kwidziński, Z., Rogoziński, T., Smardzewski, J., 2020. The idea of mass customization in the door industry using the example of the company Pporta KMI Poland. Sustainability (Switzerland) 12.
https://doi.org/10.3390/su1209....
15.
Simić, I., Džinčić, I., Palija, T., 2023. The influence of moisture content on strength of window corner joint. Drewno. Prace Naukowe, Doniesienia, Komunikaty = Wood. Research Papers, Reports, Announcements 66.
https://doi.org/10.53502/wood-....
16.
Skorupińska, E., Wiaderek, K., Matwiej, Ł., Sydor, M., 2021. Experimental verification of the joints strength features in the quality control of the mass-produced upholstery frames. MATEC Web of Conferences 338, 01024.
https://doi.org/10.1051/matecc....
17.
Wang, Y., Wang, T., Debertolis, M., Crocetti, R., Wålinder, M., Blomqvist, L., 2024. Glulam frame corner joints built of birch plywood and mechanical fasteners: An experimental, analytical, and numerical study. Eng Struct 310, 118112.
https://doi.org/10.1016/j.engs....
18.
Yerlikaya, N.C., 2014. Investigation of optimum dowel spacing for corner joints, which are reinforced with glass-fiber fabric in case-type furniture. Wood Research 59, 191–300.
19.
Yerlikaya, N.C., 2013. Failure load of corner joints, which are reinforced with glass-fiber fabric in case-type furniture. Scientific Research and Essays 8, 325–339.
